Product Code
W-SDDB
Barcode (GTIN-13)
09421006252858
Overall Size
330mm × 239mm
Download Install Manual (PDF) Download Catalogue (PDF)
💡 DIY Installation: The W-SDDB installs into timber, PVC and metal door panels using a supplied cutting template. No glazier required. Full step-by-step instructions are included and available to download above. For thicker panels up to 52mm, see the tunnel model W-SDDTB.
Dogwalk® Wood Fitting · Small Dog Door
W-SDDB Wood Fitting Small Dog Door Slim Line — Brown
The Dogwalk® W-SDDB is a slim line wood fitting small dog door in brown, designed for installation into timber, PVC and metal panels between 11mm and 30mm thick. Easy to install at home using the template supplied, with no glazier required. The full brush weather seal keeps operation draught-free, smooth and quiet, while the 4-way locking system gives you full control over your pet's access. 3-year manufacturer's warranty. Designed in New Zealand by Pet-Tek International since 1999.
Specifications
Panel Thickness
11mm – 30mm
Locking
4-way manual
Flap Size
240mm × 180mm
Compatible Panels
Wood, PVC, Metal
Finish
Brown
Recommended For
Small Dogs
Frame Projection
Inner Frame
11.57mm projection depth
Outer Frame
9.6mm projection depth
Key Features
- Full brush weather seal — draught-free, smooth and quiet operation
- 4-way manual locking: open, in-only, out-only, fully locked
- UV-stabilised high-impact polycarbonate flap — same material as aircraft windows
- All stainless steel screws, rust resistant for long-term durability
- Easy DIY installation using supplied template, no glazier required
- Brown finish, ideal for darker timber doors and brown PVC frames
- Suits timber, PVC and metal panels 11mm to 30mm thick
- 3-year manufacturer's warranty
- Designed in New Zealand by Pet-Tek International since 1999
Enquire About This Product →
📏 Is this flap the right size for your dog? The W-SDDB suits small breeds up to roughly 10–12kg through its 240mm × 180mm flap. Measure your dog at the shoulders and the widest point of the chest, and size up if they fall between doors. See how to measure your dog or use the Pet Door Selector before ordering.
Watch: How a Wood Fitting Dog Door Is Installed
Watch the install — then grab your tools
- Cutting template supplied in the box — mark the opening straight onto your door
- Panel range: 11–30mm for the W-SDDB — timber, PVC or metal doors
- Fit at the right height: flap base level with the bottom of your dog’s chest when standing
DIY installation — no glazier required. A drill and a jigsaw are all you need.
Frequently Asked Questions
The W-SDDB is designed for small dog breeds. The flap opening is 240mm × 180mm, suitable for dogs up to approximately 10–12kg depending on build. Always measure your dog at the shoulder and widest chest point before ordering. Use the Pet Door Selector for a personalised recommendation.
Both have the same flap and frame size. The W-SDDB is the slim line model for panels 11mm to 30mm thick. The W-SDDTB is the brown tunnel model with a self-lining tunnel extension, suited to thicker panels up to 52mm. If your door panel is between 30mm and 52mm, choose the W-SDDTB.
Yes. The W-SDDB is designed for DIY installation and includes a cutting template to mark and cut the opening. No glazier is required, and basic tools are all you need. Full step-by-step instructions are included in the box and available to download above.
Yes — the W-SDDW is the white version with identical specifications, better suited to lighter timber doors and white PVC frames.
Yes. Pet-Tek International ships worldwide from Auckland, New Zealand, supplying dog owners, pet retailers and trade customers across NZ, Australia, UK, Europe, the US, South Africa and more. Contact us for shipping enquiries.
The inner frame projects 11.57mm and the outer frame 9.6mm from the panel face. The flap-to-body gap is machined to a near-zero tolerance and finished with a full brush seal, so there is no daylight around the flap for a draught to use.
Retailers & Trade Buyers
Stock the W-SDDB. Pet-Tek International is a dog door manufacturer and wholesale pet door supplier since 1999 — supplying pet stores, hardware chains, garden centres and glaziers in 20+ countries. Trade pricing, export support, and local stock in Melbourne & Sydney for Australian trade buyers.
